3 Axle Skeleton Trailer
High-durability 3 axle skeleton trailer with premium specs. Ideal for 20ft/40ft container logistics. Click to learn more!
Minimum order quantity: 1 unit
- Overview
- Recommended Products
Product Details
The 3 axle skeleton trailer is a premier intermodal transport solution specifically engineered to streamline container logistics with maximum structural integrity and weight efficiency. Built to withstand the rigors of high-frequency port operations, this chassis provides exceptional durability and precise specifications, ensuring the secure transport of ISO containers while optimizing fuel consumption for long-haul and short-sea shipping cycles.
Product Parameter Table
| Parameter | Detailed Specifications |
| Payload Capacity | 40,000 kg – 60,000 kg |
| Overall Dimensions | 12,500mm × 2,500mm × 1,550mm (Customizable) |
| Main Beam Material | Q345B / T700 High-strength Steel |
| Axle Type | 3 Axles, 13T/16T FUWA/BPW/L1 Brand |
| Twist Locks | 4 / 8 / 12 sets (ISO Standard) |
| Tires | 12R22.5 Tubeless Tires (12 units + 1 spare) |
| Landing Gear | JOST / FUWA 28T Two-speed Manual |
Applications
The 3 axle skeleton trailer is exceptionally effective in application areas such as maritime port terminals, where rapid container turnaround is essential. It is also the preferred equipment for inland dry ports and intermodal rail hubs for the efficient transfer of freight. Its lightweight yet robust design makes it ideal for navigating both high-speed highways and industrial port zones, serving as a critical link in the global supply chain.
Packaging and Transportation
The 3 axle skeleton trailer is coated with anti-rust wax and professionally reinforced before shipment. We can provide roll-on/roll-off, bulk carrier, and container transport services according to customer needs. Our team will ensure safe and timely delivery of your goods to your destination port.
FAQ
Q: What is the load capacity of this trailer?
A: Depending on your working conditions and road standards, it can carry 40-60 tons of cargo.
Q: Can the sidewall height be customized?
A: Yes, we can customize the sidewall height and thickness according to your cargo requirements.
Q: Does it use mechanical suspension or air suspension?
A: Both mechanical suspension and air suspension are available.
About Us
Since 2005, we have been a professional manufacturer and exporter of semi trailers and heavy-duty vehicles. With strict quality control and mature production technology, we provide durable and affordable trailers to customers in Africa, the Middle East, Southeast Asia, and Central and South America. We support customized services, fast delivery, and reliable after-sales service.
